Mr. Yogi G-1 Bar
Description
Single Flavour with Pump & Table Top Machine
Features :-
• Compact model and exquisite look.
• New Tropicalised design resulting in high product output with low power consumption
• The machine is easy to use
• Insulated dispense head tap made of excellent insulating material
• Provide gravity feed valve system that mixes air naturally (over run up to 40%)
• Stainless steel freezing cylinders with direct expansion -cooling system ensuring rapid operation.
• Provide unique hardness control to ensure perfect product consistency of frozen yogurt every time.
• Specially crafted beaters with delrin beater blades.
• Independent refrigeration to the hopper ensures the mix is thoroughly chilled both during production and during break.
• Thermometers to constantly control storage temperature of frozen yogurt mix inside the hopper at 4 Degree Centigrade.
• The machine with air-cooled condenser.
• Environmental friendly CFC free refrigerant and CFC free thermal insulation.
Specifications
| Number of Flavours | Single Flavour |
|---|---|
| Output | 15 Ltr. Per Hour (11 KG Per Hour) |
| Capacity | 120 Cups per Hour |
| Pump | No (It gives over run Increase the ice cream volume upto 40%) |
| Tank (Hopper) Capacity | 7 Ltr. |
| Placing Type | Table Top Model |
| Installed Power | 1.3 kw |
| Dimension | 460 X 660 X 715 (W x D x H) |
| Voltage | 220 Volt. |
| Refrigerant | R-404A / R-22 |
| Frequency | 50 HZ. |
| Condenser | Air-Cooled / Water-Cooled (As per requirement) |
| Phase | Single Phase |
